Looking to streamline your concrete production? AIMIX self-loading concrete mixer is more than a mixer; it’s an all-in-one mobile concrete solution. It integrates the functions of a loader and a batching plant into one compact machine, making it exceptionally easy to operate and highly portable.
Built for the unique demands of Latin American job sites, this machine excels at producing high-quality concrete instantly—even in the most remote locations. Whether you’re working on road construction in the countryside or pouring foundations in dense urban areas, AIMIX self-loading concrete mixer adapts to the size and hardness of your aggregates with ease.
With 500+ units already in operation throughout Latin America and backed by our dedicated local dealerships, you’re choosing reliability that’s supported nearby.
Hot Selling Models
AIMIX AS3.5 and AS4.5 are very popular among our customers. These two models can meet the needs of small to medium construction projects, such as road construction, foundation laying, house construction in remote area. Most importantly, AIMIX self loading concrete mixer has a Rapid ROI: The AS-3.5 model achieves full cost recovery in approximately 1.9 months.
AS3.5Self Loading Concrete Mixer
AS3.5 | Sales of 500+ units in Latin America
Compact and ideal for narrow roads and scattered construction sites;
Low maintenance costs and high profitability;
Get A Quote
Discharging capacity3.5m³/batch
Concrete production14m³/h
Engine modelCUMMINS
Maximum speed35 km/h
Maximum slope45°
AS4.5Self Loading Concrete Mixer
AS4.5 | Higher productivity, ideal for medium-intensity job sites
Improved climbing ability and maneuverability, ideal for complex terrain
Ideal for residential areas, industrial sites and medium-sized projects
Get A Quote
Discharging capacity4.5m³/batch
Concrete production18m³/h
Engine modelCUMMINS
Maximum speed45 km/h
Maximum slope45°
More Models of the Self Loading Concrete Mixer
Aimix self-loading concrete mixer is easy to operate and can be quickly applied to various construction sites, improving the efficiency of concrete production and reducing labor costs. They are widely used in various construction and infrastructure projects in Latin America market.
What Types of Project Is Self Loading Concrete Mixer Used For?
Aimix self loading concrete mixer can be used for the following concrete mixing projects:
1. Repair roads, bridges, and harden pavements projects.
2. Precast concrete pouring project.
3. Floor construction.
4. House construction & Building foundations.
5. Water canals project.
Road Construction
For Precast Concrete Elements
Construction of Residential Buildings
Foundation Laying
Laying the Building Foundations
Warehouse Construction
AS-3.5 Self-Loading Mixer: Maximize ROI, Minimize Costs
4-in-1 system: One person – Handles the entire workflow from loading to pouring..
Go-Anywhere Capability: Off-grid operation and high maneuverability for rugged or narrow jobsites.
Rapid ROI:
Payback in 1.9 months (AS3.5 as an example)
Cost Cutting:
–$12 per m³
(versus ready-mixed concrete)
Get A Quote
The Benchmark Case of AIMIX Self Loading Mixers
Four custom-built AIMIX 4m³ self-loading mixer trucks have been commissioned and dispatched to our client’s site, where they will play a pivotal role in Huawei’s infrastructure project. This deployment sets a new benchmark for efficient concrete solutions in construction projects.
– Local Warehouse: Ensures prompt maintenance & spare parts availability;
– China’s No.1 Exported Brand: 3500+ global installations guarantee proven reliability;
– Artificial Intelligence Interactive Weighing System: High-efficiency production;
Get a Quote
Feedback from Latin America Clients
Location: Peru
Capacity: 14m³/h
Challenges: Limited construction area; excessively high labor costs; time constraints.
Final use: Residential buildings in remote areas.
Get A Quote
Location: Guatemala
Capacity: 14m³/h
Challenges: The factory building is small, making it inconvenient to transport concrete.
Final use: Foundation laying of the factory building.
Get A Quote
Location: Peru
Capacity: 18m³/h
Challenges: Concrete transportation costs are high, and customers have limited budgets.
Final use: Rural housing construction
Get A Quote
Location: Honduras
Capacity: 18m³/h
Advantages: The customers want to recoup their investment as quickly as possible, AIMIX AS4.5 can achieve a payback period of 1.9 months.
Final use: Row house construction.
Get A Quote
Location: Jamaica
Capacity: 22m³/h
Challenges: Road construction projects require frequent site relocation.
Final use: Mountain road construction.
Get A Quote
Location: Guyana
Capacity: 22m³/h
Challenges: The mountain roads are rugged, making it inconvenient to transport concrete.
Final use: Mountain housing construction
Get A Quote
More Cases Of Self Loading Concrete Mixer in Latin America
AS3.5 In Jamaica
AS3.5 In Honduras
AS3.5 In Dominican
AS3.5 In Trinidad and Tobago
AS3.5 In Guyana
AS3.5 In Kazakhstan
AS3.5 In The Barbados-Road Construction
AS3.5 In El Salvador-Building Construction
AS3.5 In Guatemala – Building Constuction
AS3.5 In Honduras-Building Construction
AIMIX Self Loading Concrete Mixer Construction On-site
Intelligent Operation System
1. The first 13.5-inch high-definition touch screen for easy operation;
2. Artificial Intelligence Interactive Weighing System: easy to operate, 10 minutes to get started;
New Generation of Dynamic Weighing System
1. The first oil cylinder measurement and control weighing technology;
2. Weighing error is less than 2% relative to similar products weighing accuracy increased by 10 times;
Rust-proof Treatment
The vehicle structural parts are all sandblasted, and the thin plate parts are pickled and phosphated, which has good anti-rust effect;
Engineering Pattern Tires
Engineering pattern tires are specially designed for engineering vehicles, with strong grip, not easy to slip, and ensure safety in use;
Mixer Drum 270 Degree Rotation
It can realize multi-angle and multi-directional unloading, which greatly reduces the labor intensity for concrete paving and improves the production efficiency of paving and grinding;
High Efficiency Mixing
Made of high manganese steel, with 6 spiral blades and 8 stirring push plates, the tank rotates 22-23 times per minute, with fast feeding, fast discharging and uniform stirring, saving time and improving efficiency;
Technical Parameters Of Aimix Self-loading Concrete Mixer:
| AS-1.2/1.8/2.6 Self Loading Mixer | AS-3.5/4.5 Self Loading Concrete Mixer | AS-5.5/6.5 Self Loading Concrete Mixer |
|---|
| Equipment Model | AS-1.2 Self Loading Mixer Truck | AS-1.8 Self Loading Mixer Truck | AS-2.6 Self Loading Concrete Mixer truck |
| Discharge Capacity | 1.2 m³ | 1.8 m³ | 2.6 m³ |
| Engine Model | Yunnei 490 Turbo-Charged | Yuchai 4102 Turbo-Charged | Yuchai 4102 Turbo-Charged |
| Rated Power | 55 kw | 78 kw | 78 kw |
| Gear Box Model | ZL-265 Power Shift Gearbox | ZL-280 Power Shift Gearbox | ZL-280 Power Shift Transmission |
| Gear | 2 Forward 2 Back | 2 Forward 2 Back | 4 Forward 4 Back |
| Fuel Tank | 63 Liters | 75 Liters | 75 Liters |
| Total Hydraulic System Capacity | 63 Liters | 75 Liters | 75 Liters |
| Oil Tank | 16 Liters | 16 Liters | 16 Liters |
| Reducer | KY07-2-0 | HJ80-43 | HJ80-43 |
| Hydraulic Pump | CBFC 50/32 | CBGQ 2050/2032 | CBGQ 2050/2032 |
| Hydraulic Motor | BM5-125 | BM5-160 | BM5-160 |
| Water Tank | 400 L | 500 L | 500 L |
| Water Supply | Time Relay | Time Relay | Time Relay |
| Overall Dimensions(L*W*H) | 6400×2550×3300 | 7300×2650×3750 | 7860×2750×4100 |
| Wheelbase (mm) | 2300 | 2600 | 2800 |
| Curb Weight (Kg) | 4185 | 6500 | 6500 |
| Drive Form | Torque Converter | Torque Converter | Torque Converter |
| Drum Rotate | 270º | 270º | |
| Max.Speed (Km/h) | 30 | 30 | |
| Maximum Grade | 30º | 30º | 30º |
| Maximum Turning Radius (mm) | 4700 | 5300 | 5300 |
| Minimum Ground Clearance (mm) | 280 | 380 | 380 |
| Equipment Model | AS-3.5 Type A Self Loading Mixer Truck | AS-4.5 Self Loading Mixer Truck |
| Discharge Capacity | 3.5 m³ | 4.5 m³ |
| Engine Model | YUCHAI 4105 Turbo-Charged | YCD4J22G |
| Rated Power | 85 kw | 85 kw |
| Gear Box Model | ZL-280 Power Shift Gearbox | ZL-280 Power Shift Gearbox |
| Gear | 2 Forward 2 Back,Front Wheels Steering | 2 Forward 2 Back,Front Wheels Steering |
| Fuel Tank | 75 L | 230 L |
| Total Hydraulic System Capacity | 75 Liters | 170 Liters |
| Oil Tank | 16 Liters | 16 Liters |
| Reducer | HJ80-43 | KY07-5-J |
| Hydraulic Pump | CBGQ 2040/2080 | Interpump |
| Hydraulic Motor | BM5-160 | HAA2FM56/61W-VTD527 |
| Water Tank | 620 L | 660 L |
| Water Supply | Time Relay | Time Relay |
| Overall Dimensions(L*W*H) | 7830×2680×4170 | 7640×2870×4750 |
| Wheelbase (mm) | 2900 | 2480 |
| Curb Weight (Kg) | 7500 | 9000 |
| Drive Form | Torque Converter | Torque Converter |
| Max.Speed (Km/h) | 30 | 35 |
| Maximum Gradeability | 30º | 30º |
| Maximum Turning Radius (mm) | 5300 | 4800 |
| Minimum Ground Clearance (mm) | 380 | 330 |
| Equipment Model | AS-5.5 Self Loading Mixer Truck | AS-6.5 cbm Self Loading Mixer Truck |
| Discharge Capacity | 5.5 m³ | 6.5 m³ |
| Engine Model | FAW XICHAI 6110 Turbo-Charged | Weichai deutz 6105 Turbo-Charged |
| Rated Power | 110 kw | 92 kw |
| Gear Box Model | ZL-315 Power Shift Gearbox | ZL-315 Power Shift Gearbox |
| Gear | 2 Forward 2 Back, Front Wheels Steering | 2 Forward 2 Back |
| Fuel Tank | 180 L | 370 L |
| Total Hydraulic System Capacity | 180 Liters | 278 Liters |
| Oil Tank | 16 Liters | 16 Liters |
| Reducer | HJ80-43 | KY07-5-J |
| Hydraulic Pump | CBGQ 2050/2032 | Interpump |
| Hydraulic Motor | USA SUNNY 56 | SUNNY63 |
| Water Tank | 860 L | 1465 L |
| Water Supply | Time Relay | Time Relay |
| Overall Dimensions(L*W*H) | 8450×3100×4580 | 8450×3050×4830 |
| Wheelbase (mm) | 3350 | 2850 |
| Curb Weight (Kg) | 11200 | 12520 |
| Drive Form | Torque Converter | Torque Converter |
| Drum Rotary | 270º | |
| Max.Speed (Km/h) | 42 | 40 |
| Maximum Gradeability | 30º | 30º |
| Maximum Turning Radius (mm) | 6200 | 4800 |
| Minimum Ground Clearance (mm) | 350 |
Note: Due to equipment upgrades, the parameters will be adjusted without notice.
Self Loading Concrete Mixer With Pump – The Best Construction Solution
Reduce labor costs
Multifunctional combination
Adapting to complex conditions
Efficient construction
